Description
Features of the SB i30 Evaporative Air Cooler:
| Maximum Flow: | 30.000 m³/h |
| Electrical Power: | 220 V |
| Quantidade de bombas: | 1 unidade |
| Flow per pump: | 2.500 lts/h |
| Water inlet: | Torneira boia |
| Propeller Set: | Axial – 03 plastic blades |
| Controller Panel: | Frequency inverter |
| Air distributor: | Grelha de plástico com swing |
| Water tank: | 50 liters |
| Evaporative Plate: | Alta Eficiência 45º/45º |
| Weight without water: | 105 kg |
| Dimensões totais (mm): | A: 1250 x L: 1180 x P: 1250 |
| Dimensões saída de ar (mm): | 795 x 795 |
| Dimensões do duto (mm): | A: 100 x L: 780 x P: 700 |
| Abertura no teto (mm): | 720 x 720 |
| Embalagem montado (mm): | A: 1310 x L: 1310 x P: 1310 |
| Engine: | 4,0 cv |
| Total Electrical Consumption kW/h: | 3,07 kW/h |
| Functions: |
|
Benefits of the SB i30 Evaporative Air Cooler:
- Easy installation;
- Low noise level;
- High efficiency motor;
- Does not use toxic gases;
- Constant air renewal;
- Maintenance of air circulation;
- Low electricity consumption;
- Reduction of ambient temperature;
- Open environment operation.
Advantages of the SB i30 Evaporative Air Cooler:
- Complete inverter;
- Level sensor made of high-resistance polypropylene;
- Automotive bearing, does not require lubrication;
- Air diffuser with horizontal and vertical direction;
- SB i30 evaporative air cooler control panel;
- Propeller set with greater efficiency and exclusive design;
- Water pump with low electrical consumption and large water flow;
- Evaporative panel with high air coolering power and anti-algae protection;
- Complete controller panel with timer, speed control, water flow control and total remote control.
SB i30 Evaporative Air Cooler Control Panel:
- TIMING: Timed;
- CLOCK: Clock set;
- REVERSE: Disables the water pump;
- AUTO: Equipment works automatically;
- SWING: Enables air oscillation in the environment;
- SET: Software adjustment key and error viewer.
- UP/DOWN ARROWS: Controls engine speed.
- COOL(CLIMATIZE): Water flow in the evaporative panels;
- CLEAN: Activates the water drainage from the reservoir and the engine and pump stop working;
Applications of the SB i30 Evaporative Air Cooler:
-
- Churches;
- Clubs;
- Factions;
- Stocks.
- Wholesale;
- Industries;
- Shopping malls;
- Furniture store;
- Supermarkets.
